STB-Digital Terrestrial Receiver(MPEG4 SD) (STB DV

DVB-T Features: - Based on EMMA3SL-LP single chip processor - Fully DVB-T & SD MPEG-2 / MPEG-4 / H.264 compliant - Wide screen 16:9 and normal 4:3 Aspect Ratio - Digital Audio S/PDIF Coaxial Output - Fully supports 7 Days Electronic Program Guide(EPG) - FTA or Embedded Conax CA - Various channel editing functions (favorite, move, lock, rename, sort, skip) - 4000 channels TV and Radio programmable - Channel search in automatic and manual - Software upgrades through RS232 port and OTA Specification: 1. Main System Resource - CPU : EMMA3SL-LP(288MHz) - Flash : 4Mbytes(NOR) - RAM : 64Mbytes(DDR2 SDRAM) 2. Video Decoder - Video Decode : MPEG2 MP@ML / MPEG4 / H.264 - Video Format : 720x480(NTSC), 720x576(PAL) - Aspect Ratio : 4:3 / 16:9 3. Audio Decoder - Audio Decode : MPEG-1 / MPEG-2 / MPEG-4 - Audio Output Mode : Stereo / Mono - Sampling Rate : 32KHz, 44.1KHz, 48KHz 4. Channel Decoder & TS Demux - Demod Standard : DVB-T ETS 300 744 - Demodulation : OFDM - Bandwidth : 6MHz, 7MHz, 8MHz - FFT Size : 2K, 8K - Code Rate : 1/2, 2/3, 3/4, 5/6, 7/8 - Guard Intervals : 1/4, 1/8, 1/16, 1/32 - Demultiplexer : ISO/IEC13818-1 5. AV Output - TV SCART : Video Output(CVBS) - RCA : Video Output(CVBS), Audio R/L - S/PDIF Audio Output : Coaxial
